Classic
Defiance Action Specifications
Specifications | Classic | Renegade | Rebel (3 Position) | Deviant | Deviant Elite | Deviant Elite X | Ruckus | anTi X | Ti X | Outcast |
---|---|---|---|---|---|---|---|---|---|---|
Receiver machined from one piece of aircraft-certified 416R stainless steel |
★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | Ti-6AL-4V Titanium | ★ |
Bolt machined from one piece of aircraft-certified 4340 chrome moly, and threaded for interchangeable knobs |
★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ |
Wire EDM-Cut, full-length lug ways result in smooth bolt operation |
★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ |
All material pre-hardened prior to machining to prevent changing dimensions or shape during heat treat |
★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ |
Actions available in Short (Rem. Short Action), XM (Defiance proprietary intermediate length), Medium (Previously called XM Plus), and Long (Rem. Long Action) lengths to accommodate most popular cartridges |
Not available in XM or Medium | Not available in XM | Not available in XM | ★ | Short Only | Short Only | ★ | ★ | Short, Medium, and Long Only | Short Only |
Right and Left hand configurations available | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ |
Right Bolt / Left Port or Left Bolt / Right Port configurations available |
★ | Single Shot (Solid Bottom Only) | Single Shot (Solid Bottom Only) | ★ | ★ | ★ | ||||
Available Magazine cuts – Wyatts or Remington length hinged floor plates, AICS, AI/AW detachable magazines and Single Shot |
★ | AW Mag Cut or Single Shot Only | AW Mag Cut or Single Shot Only | ★ | Single Shot (Solid Bottom Only) | |||||
Available Magazine cuts – Wyatts length hinged floor plates, and AI/AW detachable magazines |
★ | ★ | ★ | ★ | ★ | Not Available | ||||
Customizable – our sales team will assist you in choosing from among our many options |
★ | ★ | ★ | |||||||
One-piece bolt machined in one operation enabling guaranteed headspace tolerance of +/- .001″ |
★ | ★ | ★ | ★ | ★ | ★ | ||||
Integral scope rail | ★ | ★ | ★ | ★ | ★ | ★ | ||||
Integral recoil lug | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ★ | ||
Sliding plate extractor controlled round feed with blade ejector | ★ | ★ | Optional | |||||||
anTi Cuts available | ★ | ★ | Deviant GA Hunter (Receiver Only) | N/A | ★ | Ruckus GA Hunter (Receiver Only) | ★ | ★ | ||
.750″ diameter bolts (338 Lapua, 300 Norma etc.) available | Not available in 750 | ★ | ★ | ★ | ★ | ★ | ||||
Recessed, flat, and cone nose available | ★ | ★ | ||||||||
Limited bolt nose options available | Recessed Bolt Nose | Recessed Bolt Nose | Recessed Bolt Nose | Elite Bolt Nose | Elite Bolt Nose | Recessed Bolt Nose | Recessed Bolt Nose | Shell Holder Bolt Nose | ||
Enhanced firing pin design, sliding plate extractor controlled round feed with blade ejector and .850” additional barrel threads and bedding surface forward of the recoil lug |
★ | ★ | ||||||||
Modern muzzle loader action with flat bolt nose and “shell holder” style bolt face, Single Shot solid bottom and 20 T.P.I. barrel threads (this is a rifle action that requires an FFL transfer) |
★ | |||||||||
6mm ARC / 6 PPC / Grendel available with limited bolt nose options. Choose from AI/AW magazine cut or Single Shot |
★ | Elite CRF Bolt Nose with Sliding Plate Extractor and Blade Ejector |
Elite CRF Bolt Nose with Sliding Plate Extractor and Blade Ejector |
Elite CRF Bolt Nose with Sliding Plate Extractor and Blade Ejector or Recessed Bolt Nose with Mini 16 Extractor |
Recessed Bolt Nose with Mini 16 Extractor | Recessed Bolt Nose with Mini 16 Extractor |
